This is a 25 Pack of SAB North America 13mm - 18.0mm Gray Plastic Cable Gland. Its part number is PPG-21. This item comes as pictured and does not include any additional parts or accessories.
Specifications:
- Manufacturer: SAB North America
- Part # PPG-21
- Thread: PG 21
- Material: Polyamide 6
- Color: Gray
- Temp Range (Permanent): -20°C to 100°C
- Temp Range (Intermittent): -30°C to 150°C
- Protection Class: IP 68 - 5 Bar
- Flammability: V2 (according to UL 94)
- Approvals: cULus, cCSAus, DNV-GL, CE
- Clamping Range: 0.512 - 0.709 in. (13.0 - 18.0 mm)
- Thread Diameter: 1.114 in (28.3 mm)
- Wrenching Flats: 1.299 in (33 mm)
- Thread Length: 0.433 in (11 mm)
- Height (in): 1.457
- Locknut P/N: LPG-21 (Included)
- Torque Values: Torque Values for Polyamide Glands
